The Foton EST 460HP 8x4 Cummins Diesel Euro 5 Dump Truck is a heavy-duty haulage vehicle engineered for reliability and efficiency. Powered by a robust Cummins diesel engine, it delivers exceptional load-bearing capacity and adapts to harsh working conditions, while complying with Euro 5 emission standards for global market access. Ideal for construction, mining and municipal projects, it ensures stable operation and cost-effective logistics.
Technical Specifications Reference
| Technical Parameters | Engineering Specifications |
|---|
| Drive Wheel | 8x4 (12 Wheels + 1 Spare Tire) |
| Chassis Platform | Foton Auman EST Heavy-duty Series |
| Engine Brand & Model | ISG12E5-460 (Cummins Series, Euro 3 / Euro 5 ) |
| Max Horsepower | 460 HP (Max Torque: 2200 N.m) |
| Transmission | Fast 12JSDX240TA (12 Forward Speed, Manual) |
| Front Axle | 9T Double Front Axles with Drum Brake |
| Rear Axle (Drive Axle) | 16T Hub Reduction Axle, Ratio: 5.26 |
| Tire Specification | 12.00R20 (Radial Steel Wire Tires, 18PR / 12.00R20) |
| Brake System | Dual Circuit Air Brake, ABS Equipped |
| Cargo Box Volume | 25 - 28 $m^3$ (Heavy-duty Loading Area) |
| Cargo Box Material | High Tensile Steel Q355, Bottom: 8mm, Side: 6mm |
| Lifting System | Front Hydraulic Lifting Mechanism |
| Fuel Tank | 350L Aluminum Alloy Tank with Lock Cap |
| Overall Dimensions | Approx. 10,350mm*2,550mm*3,450mm |
Core features
The power system is powerful.
Equipped with Cummins/Yuchai engines
Power output ranges from 340HP to 460HP, meeting the requirements of heavy-duty operations
Maximum torque is 2100 N·m to 2300 N·m, featuring high torque at low RPM, fuel-efficient and durable
Supports multiple emission standards such as Euro 3, Euro 5, and Euro 6, adapting to global market regulations
Bulk order enjoy big preferential
Get a Free Quote Now
Super strong load-bearing capacity
8×4 four-wheel drive design, legal load capacity can reach 31T to 50T
Front double axle 2×9T + rear double axle 2×16T, GVW maximum 49T
Truck volume 20㎥ to 30㎥ customizable, suitable for large-scale earthwork operations
Compared with 6×4 models, single trip transportation capacity increases by 30% to 40%, and operational efficiency is higher
Main application scenarios
Southeast Asia: Coal mines, nickel mines, infrastructure, ports
Africa: Mines, road construction, agriculture
Middle East: Oil and gas engineering, urban construction, quarrying
Ready to enhance your transport efficiency?
Get a Free Quote Now
Chengda Group Established in 2003,23 Years Manufacturing Experience · Exported to 80+ Countries. Our Trucks Are Sold To Africa, South Africa, Central Asia, The Middle East, South America, Southeast Asia, Asia, Eastern Europe ,Latin America, And Other Regions.
Our company sincerely invites customers from home and abroad to visit our factory for on-site inspections, tour our semi-trailer production line, welding process, and testing equipment, and closely examine raw materials, semi-finished products, and finished products. Customers will gain a direct understanding of the product manufacturing process and quality. Our professional technicians and foreign trade team will accompany you, providing one-on-one answers to questions regarding product configuration, customization solutions, pricing, and delivery time, allowing you to experience our Dump Truck strength firsthand.
