Why Choose the SHACMAN X3000 Tipper Truck？
Steep quarry slopes, thick mud, and fully loaded 30–40 ton hauls. The SHACMAN X3000 6×4 Dump Truck delivers:
Weichai WP Series Engine (380–460 HP)：The heart of the SHACMAN X3000 6×4 Dump Truck is a high-torque, field-proven Weichai engine, producing up to 2,100 N·m of torque at low RPMsSHACMAN. This means strong pulling power from a standstill, no struggling or stalling when loaded. It climbs, accelerates, and powers through mud like no other.
Technical parameters
| Technical Parameters | Engineering Specifications |
|---|
| Drive Wheel | 8x4 (12 Wheels + 1 Spare Tire) |
| Chassis Platform | Shacman X3000 Premium Heavy-duty Platform |
| Engine Brand & Model | WP12.430E201 (Weichai Power, Euro 2 / Euro 3 Standard) |
| Max Horsepower | 430 HP (Option: 380 HP / 400 HP) |
| Transmission | Fast 12JSD200T (12 Forward Speed, Synchronizer) |
| Steering Gear | Genuine ZF8118 Hydraulic Power Steering |
| Front Axle | MAN 9.5 Ton Heavy-duty Front Axles x 2 |
| Rear Axle (Drive Axle) | MAN 16 Ton Double Reduction Axles, Ratio: 5.26 |
| Tire Specification | 12.00R20 or 13.00R20 (Radial Steel Wire Tires) |
| Cargo Box Cubage | 25 - 30 $m^3$ (According to cargo specification) |
| Cargo Box Material | High Tensile Steel Q355; Bottom: 8mm, Side: 6mm |
| Hydraulic Lifting Cylinder | HYVA Front Lifting Hydraulic Cylinder System |
| Fuel Tank Capacity | 400L Aluminum Alloy Fuel Tank with Anti-theft Cap |
| Overall Dimensions | Approx. 10,500mm*2,550mm*3,450mm |
Ready to enhance your transport efficiency?
Get a Free Quote Now
Product Details
Next-Gen Fuel Efficiency : Features an advanced powertrain optimization system that reduces fuel consumption by up to 10-12% compared to standard tippers.
Premium Driver Ergonomics : The X3000 luxury cabin is equipped with dual-seal noise reduction technology, multi-angle air-suspension seats, and an intelligent control panel.
Ultimate Frame Specifications : Constructed with an 850mm ultra-wide high-strength steel frame and reinforced MAN reduction axles to eliminate frame twisting under severe overload.
Optimized U-Shaped Tipping Box : High-tensile steel construction with a smooth internal arc design guarantees rapid unloading, reduces residue sticking, and increases daily transport cycles.
Global Support & Unmatched ROI : Backed by Shacman's global warranty and extensive spare parts warehouses, minimizing maintenance downtime and maximizing fleet ROI.
About US
Chengda Group Established in 2003,23 Years Manufacturing Experience . Exported to 80+ Countries.We provide high-quality products and have obtained CCC, BV, ISO, and WMI certifications, with cumulative export value reaching US$5 billion. We are a leading supplier in the industry, exporting over 3,000 trucks, trailers, and cars annually. We have exported a large number of trucks to Africa! We have numerous loyal and stable customers from all over the world. Our trucks are exported to Africa, South Africa, Central Asia, the Middle East, South America, Southeast Asia, Asia, Eastern Europe, Latin America and other regions.
With proven quality and a strong brand image, we have obtained ISO9001, CCC, ECE, and BV certifications. As a manufacturer with its own factory and R&D capabilities, we currently have 200 employees, annual sales of 60 million, and our products are widely recognized in Southeast Asia, the Middle East, Africa, South America, and Central America.
