Our customers chose the 4 Axle Bulk Cement Semi Trailer because of its comprehensive advantages in terms of large load capacity, high efficiency, compliance, safety, and long-term economic benefits. It is especially suitable for large-scale, long-distance transportation of powdery materials (cement, fly ash, etc.).
Product Specifications
| Item | Parameter |
|---|
| Product Name | 4-Axle Large-Capacity Bulk Cement Transport Semi-Trailer |
| Rated Volume | 40-60 m³ (Customizable) |
| Rated Load | 40-60 Ton (40000-60000kg) 40-60 吨 |
| Axle Quantity | 4 standard heavy-duty axles |
| Tank Material | Q345 high-strength anti-corrosion steel |
| Tank Thickness | 5-6mm (Main body) / 5-6mm |
| Overall Dimension (L×W×H) | 12500mm × 2500mm × 3800mm (Customizable) |
| Unloading Method | Pneumatic discharge (air compressor driven) |
| Working Pressure | 0.2MPa (Standard) |
| Tire Specification | 12R22.5 heavy-duty rubber tire |
| Tire Quantity | 8 pcs |
| Suspension System | Mechanical leaf spring suspension |
| Brake System | Dual-line pneumatic brake + ABS anti-lock system |
| Kingpin Size | 50mm / 90mm optional 50mm/90mm |
| Paint Process | Sandblasting + Anti-rust primer + Wear-resistant topcoat |
| Gross Weight | About 10000-13000kg |
| Applicable Materials | Bulk cement, fly ash, lime powder, mineral powder, chemical powder |
| Optional Accessories | Air compressor, ladder, manhole cover, tool box, anti-static device |
Custom trailer available, contact us to get lowest factory cost!
Get a Free Quote Now
Features
Highly Efficient Unloading – No Blockage, Low Residue
Optimized fluidized bed structure for fast unloading and low residue
Sealed tank for dust-free transport, moisture-free, and loss-free operation
Compatible with air compressor systems for fast on-site unloading and reduced waiting time
Durable Structure, Low Failure Rate
High-strength steel tank for corrosion and fatigue resistance
Standard configuration with renowned axles/brakes/suspension for high reliability and good resale value
Simple maintenance, suitable for long-term, high-intensity operation
Product Applications:
Highly versatile and multi-purpose.
Can transport: cement, fly ash, mineral powder, lime powder, dry-mixed mortar, chemical powders, etc. Applicable to various scenarios including building materials, infrastructure, mixing plants, and power plants.
